A mini vehicle with Formula 1 racing car suspensions, but which can move with the same efficiency and safety off-road.
Children's electric vehicle, car. Tricycle for children.

Children's electric vehicle, car. Tricycle for children.

Children's electric vehicle, car. Tricycle for children.

It can be both a tilting tricycle and a anti roll car. The choice between these two different suspension systems is made by simply moving a lever from the driver. Many installations options.
Children's electric vehicle, car. Tricycle for children.

The vehicle is designed with anthropometric data. Can be used by people with a height of 95 cm to 130 cm with the same level of ergonomic comfort. To make this possible, there are mechanisms by which the driver can adjust:
- Four parameters of the driver's seat.
- Two parameters of the steering wheel.
- The position of the accelerator and brake pedals.
Each setting has a maximum and a minimum.
All settings can be made directly and easily by the driver.
Children's electric vehicle, car. Tricycle for children.

Children's electric vehicle, car. Tricycle for children.

No lubrication required. Self-lubricating PTFE is used on all axles.
The vehicle can accept a load of 120 Kg.
The height of the vehicle from the ground can be adjusted by the driver. The stiffness of the suspensions can be adjusted in the same way.
Children's electric vehicle, car. Tricycle for children.

The electric motor is integrated in the rear wheel.
Each wheel has disc brakes.
Children's electric vehicle, car. Tricycle for children.

Vehicle parameters:
Width (from the centers of the two front wheels):
800 mm
Width:
946 mm
Length (from the center of the front axle to the center of the rear wheel):
1.200 mm
Length
1.658 mm
Height from the ground:
100 mm
Chassis height from the ground:
100 mm
Wheel diameter:
304 mm
Vehicle weight (including batteries and electric motor):
29,750 Kg
Required power:
150 watt
Maximum speed (maximum speed can be adjusted by the parents):
40 Km/h
Construction materials:
Steel
Children's electric vehicle, car. Tricycle for children.

Suspension geometry:
Angle camber:
-10
Angle toe:
+20
SCRUB RADIUS KPI (King pin inclination) or SAI (Steering axis inclination)
160
Angle caster:
+100
Angle Accerman
Yes
Vertical displacement of front wheels:
-70 mm ~ +70 mm
Vertical rear wheel displacement:
-70 mm ~ +70 mm
Inner wheel radial when turning:
2.500 mm
Minimum turning radius:
2.610 mm
Children's electric vehicle, car. Tricycle for children.

The steering axle is constructed in such a way that it tends to move forward, thus ensuring maximum passive safety for the driver
Children's electric vehicle, car. Tricycle for children.

The transmission from the steering wheel to the wheels is done with gears in a ratio of 1/2
